CP-4780-5

规格：5GAL、55GAL
产品简介：CP-4780-5 is used in convection and forced-cooled pipe cable systems.
同类产品：

Archine Refritech RAB  5

Click PDF at bottom left of the page to get more product details.

CP-4780-5

PRODUCT DESCRIPTION
CP-4780-5 is used in convection and forced-cooled pipe cable systems. It is also widely used in self-contained cable systems due to its high resistance to gassing under electrical stress. CP-4780-5 is based on synthetic alkyl benzene, which has the following advantages:
- Low power factor - High volume resistivity
-Excellent oxidation stability -Excellent resistance to gassing under -Non-toxic electrical stress
-High dielectric strength -Low weight loss under vacuum
-High water tolerance -No pumping problems
-Compatible with polybutene or mineral oil
-High auto ignition point -

ELECTRICAL PROPERTIES

Power factor, 60 Hz, 100°C D-924
Initial 0.0005
After heating 96 hrs. 115°C D-1934 (Procedure A) 0.0005
Resistively, ohm-cm, 100°C D-1169, D-257
Initial 1x1015
After heating 96 hrs. 115℃ D-1934 (Procedure A) 5x1014
Dielectric Strength, kV, 25℃ D-877 >35
Dielectric Constant, 60 HZ, 100℃ D-924 2.1
Gassing Under Electrical Stress
Pirelli, Microliters/Minute D-2300 (Procedure B) <-10
*These Values are not intended for use in preparing specifications.
