食品级液压油 ArChine Hydratek NEH 系列

规格：19L、200L
产品简介：ArChine Hydratek NEH 22 is synthetic polyol ester (POE) hydraulic oil

产品介绍

ArChine Hydratek NEH 22

Food Grade Synthetic Hydraulic Oil

NSF Registration No. 152472 Place of Origin: Shanghai, China

GENERAL:

ArChine Hydratek NEH 22 is synthetic polyol ester (POE) hydraulic oil. This full-synthetic formulation has

an ashless multifunctional oxidation and rust inhibiting additive package for hydraulic fluid according to:

ISO 6743/4 (HM, HV); ISO 11158 (HM, HV); DIN 51524, parts 1 - 3 (HL, HLP, HVLP); DIN ISO 15380

(HEES); U.S.Steel 127 and 136

ArChine Hydratek NEH 22 is readily biodegradable and in nontoxic to the environment. It is recommended for

use in hydraulic equipment operating in food processing.

USDA/NSF has approved ArChine Hydratek NEH 22 under their H-1 specification for incidental contact

with food.The oil complies with FDA guidelines for food contact listed in CFR Title 21 Part 178, Section 178.3570.

FEATURES:

Full-synthetic formulation
Protect against rust and oxidation
Readily biodegradable
Reduced environmental impact
Excellent wear protection for hydraulic pumps and motors
Outstanding viscosity-temperature properties eliminate the need for seasonal changeover
Resistant to sludge and varnish formation

Applications

Systems employing multi-metal designs in pumps and other system components
High pressure vane, piston and gear pumps
Systems where very high operating temperatures are typical
In systems containing gears and bearings
Systems requiring a high degree of load-carrying capability and anti-wear protection
Resists fling-off and remains on the chain for maximum lubrication and protection
Farm implements
Forestry and logging equipment
Ski lifts

TYPICAL PROPERTIES*:

ISO Grade	22
Appearance	Light yellow transparent liquid
Density@ 20℃, g/cm3	0.935
Viscosity @ 40°C, mm2/s	23.3
Viscosity @ 100°C, mm2/s	4.92
Viscosity Index	140
Pour Point, °C	-36
Flash Point, °C（open cup）	266
Fire Point, °C	284
Foaming 24℃， 93.5℃， after24℃	10/0 15/0 10/0
Copper corrosion,100°C/3hr,grade	1

*Typical data shall not be used as product specifications.

Applications for ArChine lubricants

		ArChine Food Grade Lubricants
EQUIPMENT APPLICATION		32	46	68	100	150	220	320	460	680
Compressors	Axial	√	√	√
	Radial	√	√	√
	Reciprocating Diaphragm					√	√	√	√	√
	Reciprocating（Piston）	√	√	√
	Rotating	√	√	√	√	√
	Screw		√	√	√	√	√
	Scroll	√	√	√
Drivers	Chain Drives	√	√	√	√	√	√	√	√	√
	Electric Motors	√	√	√
	Slides	√	√	√	√	√	√	√	√
	Sliders	√	√	√	√	√	√	√	√	√
	Bearings	√	√	√	√	√	√	√	√	√
